New 4 Axis Wireless Mach3 MPG Pendant CNC Handwheel Manual Pulse

Reg Price: $??

Our Price: $??

1.Radio frequency:433 MHZ,ISM,the Tx power is 10DB and the RX sensitivity is-98DB.
2.The RF has 64 channels,the channel gap is 1Mhz.

3.Using frenquency hopping,stable and reliable.

4.Hopping transmission technology,can support 64 sets of equipment,each other is not affected.

5.100PPR manual pulse generator.

6.LCD Display:machine coordinates and workpiece coordinates X,Y,Z,A,B,C-axis.

7.LCD Display:Spindle speed value,processing feed rate value.

Using Warning:
In order to signal stability of the receiver to be installed outside the chassis.
Using the step:

1.Insert the USB receiver,wait for the automatic driver installation is completed.

2.The driver(in the CD inside) XHC-ShuttlePro.doll copies to /Mach3/PlugIns.

3.The all macro files(in the CD inside macro folder)copied to /Mach3/macro/under Mach3Mill.

4.Wireless MPG,install 2AA batteries,turn on the power switch,you can mormally use.

Band switch function:
To control the various function of the hand wheel through the band switch.

LCD display instructions:
Explanation:

1.Key success indication:when you press the button,the receives the key value,the indicator flasher about,indicating successful key operation.

2.Speed Indicator:
when the band switch to select 1X,10X,100X,1000X,the LCD display value:0.001,0.01,0.1,MPG.

3.Axis selected location:Axis selection switch position,LCD display axis selected.X:X workpiece coordinate axis,1X:X axis mechanical coordinate.

Package Include:
1pcs 4 Axis Wireless Mach3 MPG Pendant CNC Handwheel.
